V1-8/16A-E2 Overview
Optimize your automation infrastructure with the V1-8/16A-E2, a high-performance M12 sensor distribution box designed for efficient field wiring. As part of the trusted Pepperl+Fuchs V1 series, this 8-way splitter box eliminates the need for complex individual cabling to the control cabinet, significantly reducing installation time and costs. Its compact, rugged design supports dual configuration, allowing users to freely assign pins for various sensor and actuator types, providing unmatched flexibility in dynamic production environments.
Key Features & Benefits
- Flexible Dual Configuration: The unique dual configuration architecture enables independent setup of each port, supporting a wide range of sensor types (PNP/NPN, NO/NC) without hardware changes. This adaptability simplifies inventory management and system upgrades.
- Rapid Wiring with Cage Clamps: Equipped with high-quality cage clamp terminals (spring-loaded), the V1-8/16A-E2 ensures vibration-proof connections and allows for tool-free or quick-tool wiring, drastically cutting down commissioning time.
- Comprehensive Diagnostics: Integrated LED indicators provide real-time visual feedback:
- Green LED: Monitors supply voltage for each module.
- Yellow LED: Displays the switching status of individual I/O channels, enabling instant fault detection and minimizing downtime.
- Robust Industrial Design: Housed in a durable casing with an IP67 protection rating, this M12 junction box is fully dust-tight and protected against temporary immersion, making it perfect for washdown areas, outdoor installations, and dusty factories.
- Standardized Connectivity: Utilizes industry-standard M12 (5-pin) connectors, ensuring seamless compatibility with thousands of sensors, actuators, and pre-fabricated cables from major manufacturers.
Technical Specifications
- Model Number: V1-8/16A-E2
- Product Type: Sensor/Actuator Distribution Box (Splitter)
- Series: Pepperl+Fuchs V1 Series
- Number of Ports: 8 (M12 x 1, 5-pin)
- Configuration: Dual Configuration (Flexible pin assignment)
- Connection Technology: Cage Clamp Terminals (Spring-loaded)
- Max Current per Port: Typically 2A (Check specific load ratings)
- Total Current Limit: Dependent on feed module (usually up to 10-16A total)
- Voltage Rating: 24V DC (Typical operating range 20-30V DC)
- Protection Class: IP67 (IEC 60529)
- Ambient Temperature: -25°C to +70°C (-13°F to +158°F)
- Indicators: Green (Power), Yellow (Signal Status) per channel
- Certifications: UL Listed (File No. E191152), CE, CCC
Applications
The V1-8/16A-E2 splitter box is extensively used in:
- Automotive Assembly: Connecting multiple proximity sensors on welding lines and conveyors.
- Packaging Machinery: Distributing signals for photoelectric sensors and pneumatic valves.
- Intralogistics: Wiring roller conveyors and sorting systems efficiently.
- Food & Beverage: Washdown zones requiring high ingress protection.
- General Factory Automation: Reducing cabinet space by decentralizing I/O connections.
Why Choose This Distribution Box?
Our V1-8/16A-E2 units are sourced directly from authorized channels, guaranteeing genuine Pepperl+Fuchs quality and reliability. Whether you are retrofitting an existing line or designing a new smart factory layout, this distribution box offers the perfect blend of flexibility, durability, and ease of use. Backed by our technical support team and warranty, it’s the smart choice for modern industrial wiring.
