Siemens 6ES7194-3AA00-0BA0 ET 200 Connection Block
Siemens 6ES7194-3AA00-0BA0 is a Connection Block from the ET 200 range of Siemens programmable logic controllers.
Overview
The Siemens 6ES7194-3AA00-0BA0 is a Connection Block from the ET 200 range of Siemens programmable logic controllers. Key ratings: Product Type Connection Block; Rated Voltage 24 V DC; Current Consumption < 1 A. This part is offered subject to stock availability. Units are supplied new in original factory packaging.
Key Features
- Product Type: Connection Block
- Rated Voltage: 24 V DC
- Current Consumption: < 1 A
- Protection Class: IP65 / IP67
- Mounting Type: Screw mounting on standard profiles
- Connection Type: 2x M12 and 2x 7/8″ connectors
- Operating Temperature: -25 to +55 °C
Technical Specifications
| Attribute | Value |
|---|---|
| Product Type | Connection Block |
| Product Line | SIMATIC ET 200 Distributed I/O |
| Series | ET 200 |
| Rated Voltage | 24 V DC |
| Current Consumption | < 1 A |
| Protection Class | IP65 / IP67 |
| Mounting Type | Screw mounting on standard profiles |
| Connection Type | 2x M12 and 2x 7/8″ connectors |
| Operating Temperature | -25 to +55 °C |
| Part Number / Catalog No. | 6ES7194-3AA00-0BA0 |
| UPC | 662643224610 |
| Manufacturer | Siemens |
| H.S. CODE | 8537.10 |
| Standard Warranty | 1 year |
| Condition Options | New (Original Packaging) |
Why Buy from Us
This product is supplied new in original factory packaging and is backed by a standard warranty of 1 year. We ship worldwide with careful anti-static packaging and fast dispatch. Quantity discounts and repair/exchange options are available on request.
Documents
| Resource | Availability |
|---|---|
| SIMATIC Equipment Manual / Operating Instructions | Available on request — contact us with catalog number 6ES7194-3AA00-0BA0 |
| Installation & Wiring Guide | Supplied with the unit |
SIMATIC documentation is published by the manufacturer per article number. Request a copy with your order and we will supply the revision that matches your unit.
