Allen-Bradley 1794-IB10XOB6 FLEX I/O 10-In / 6-Out 24V DC Digital Combination Module
Allen-Bradley 1794-IB10XOB6 is a FLEX I/O digital combination I/O module with 10 inputs and 6 outputs.
Overview
The module pairs 10 current-sink inputs (4.8 kilohms nominal input impedance, 8 mA at 24V DC nominal on-state) with 6 current-source outputs rated 2 A per channel at 24V DC nominal. Flexbus current is 50 mA. It is an open-style module operating from -20 to 55 degrees Celsius and snaps onto a 1794 terminal base mounted on DIN rail.
Key Features
- 10 current-sink inputs + 6 current-source outputs
- 24V DC nominal on-state; 8 mA nominal input current at 24V DC
- 2 A per channel output current
- 4.8 kilohms nominal input impedance; 50 mA Flexbus current
- -20 to 55 degrees Celsius, open style
Technical Specifications
| Attribute | Value |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Product Line | FLEX I/O |
| Part Number / Catalog No. | 1794-IB10XOB6 |
| UPC | 612598137770 |
| Nominal On-State Input Voltage | 24 VDC |
| Input Type | Current Sink Inputs |
| Nominal On-State Output Voltage | 24 VDC |
| Output Type | Current Source Outputs |
| Number of Inputs | 10 |
| Number of Outputs | 6 |
| Nominal Input Impedance | 4.8 kilohms |
| Nominal On-State Input Current | 8 mA at 24 VDC |
| Nominal On-State Output Current | 2 A per Channel |
| Flexbus Current | 50 mA |
| IP | None (Open) |
| Operating Temperature | -20°C to 55°C |
| Dimensions | 9.4 x 9.4 x 6.9 cm (3.7 x 3.7 x 2.7 in) |
| Weight | 0.44 lbs (0.20 kg) |
Applications
The 1794-IB10XOB6 packs ten current-sink 24V DC inputs and six current-source outputs (2 A per channel) into one FLEX I/O terminal base slot.
