Allen-Bradley 1734-IE2C POINT I/O 2-Channel Analog Current Input Module, 4-20 mA

Allen-Bradley 1734-IE2C is a two-channel analog current input module for the POINT I/O (1734) family.

Overview

The module accepts two current inputs configurable for 0-20 mA or 4-20 mA with a 60 ohm input impedance and delta-sigma conversion producing 16-bit signed-integer data. Absolute accuracy is 0.1% of full scale at 25 degrees Celsius. Common-mode rejection is 120 dB and normal-mode rejection 60 dB. The module sits in keyswitch position 3 on a 1734-TB or 1734-TBS terminal base.

Key Features

• 2 analog current inputs, 0-20 mA or 4-20 mA
• 16-bit resolution with delta-sigma conversion; signed integer data format
• 0.1% full-scale accuracy at 25 C; 60 ohm input impedance
• 120 dB common-mode / 60 dB normal-mode rejection
• Keyswitch position 3; 1734-TB or 1734-TBS terminal base

Technical Specifications

Applications

The 1734-IE2C reads two 4-20 mA or 0-20 mA process transmitters per POINT I/O slot – pressure, level, flow and position sensors – with 16-bit resolution and 0.1% full-scale accuracy.

Why Buy from Us

This product is available new in original factory packaging, fully tested and backed by a standard warranty of 1 year. We ship worldwide with careful anti-static packaging and fast dispatch. Quantity discounts and repair/exchange options are available on request.

Documents

Certifications

Per the Rockwell Automation product certification listing. Please review the product label to confirm the certifications your specific unit carries.
