1769-ECL Overview
The 1769-ECL is an essential accessory for any Allen-Bradley CompactLogix installation. Serving as the Left End Cap for the 1769 series chassis, this component is designed to snap securely onto the left side of your processor or power supply module. While it may seem like a small part, the 1769-ECL plays a crucial role in maintaining the environmental protection and physical integrity of your PLC system.
Key Features & Benefits
- Genuine Allen-Bradley Quality: Manufactured by Rockwell Automation, the 1769-ECL is engineered to meet the exact specifications of the CompactLogix platform, ensuring a perfect fit and long-lasting durability.
- System Protection: Effectively seals the left side of the module bank, preventing dust, dirt, and other contaminants from entering the internal electronics or backplane connectors.
- Professional Finish: Provides a clean, finished look to your control panel or DIN rail installation, covering exposed edges and giving your system a polished appearance.
- Easy Installation: Designed with a simple snap-on mechanism, allowing for quick installation or removal during maintenance without the need for special tools.
- Durable Construction: Made from high-quality, flame-retardant plastic that withstands the rigors of industrial environments, resisting impact and degradation over time.
Technical Specifications
| Manufacturer | Allen Bradley |
|---|---|
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-ECL |
| Weight | 0.13 lbs (0.06 kg) |
| Module Type | End Cap/Terminator |
| Series | A and B |
| Enclosure Type Rating | None (Open Style) |
| Operating Temperature | 0-60 ?C (32-140 ?F) |
| Maximum Bus Current Draw | 5 mA at 5 volts DC |
| Backplane Current | 1.4 Amps at 24 Volts |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
Applications
The 1769-ECL is required for:
- CompactLogix Systems: Terminating the left end of a CompactLogix 1769-L controller or power supply setup.
- Expansion Banks: Closing off the left side of 1769 expansion I/O banks.
- Control Panel Assembly: Ensuring a neat and tidy layout in electrical cabinets.
- Maintenance & Repair: Replacing missing or damaged end caps on legacy systems.
Why Choose This End Cap?
Don’t compromise your system’s protection with generic parts. Our 1769-ECL is a genuine Allen-Bradley component, sourced directly from authorized channels. Whether you are building a new machine or refurbishing an existing line, this end cap ensures your PLC hardware remains secure and professional. We offer fast shipping and reliable customer support for all your automation spare parts needs.
Order your Allen-Bradley 1769-ECL Left End Cap today.
